MOTOBATT
Datasheet
Lithium Iron Phosphate (LiFePO₄) Battery
---
SPECIFICATIONS
Model No.
MOTOBATT-WM-51200-A
Dimensions
Length: 600 mm
Width: 465 mm
Height: 260 mm
Weight
About 83 kg
---
CHARACTERISTICS
Nominal Voltage: 51.2 V
Nominal Capacity: 200 Ah
Nominal Energy: 10240 Wh
Internal Impedance: ≤ 50 mΩ
Charge Voltage: 58.4 V
Discharge Cut-off Voltage: 40 V
Standard Charge Current: 100 A
Max. Charge Current: 150 A
Standard Discharge Current: 100 A
Max. Discharge Current: 200 A
Peak Discharge Current: 250 A ≤ 5 s
Cycle Life: ≥ 6000 (0.5C, 25°C, 80% DOD)
Operating Temperature
Charge: 0°C ~ +55°C
Discharge: -30°C ~ +55°C
Note:
Max. 16 parallel connections
---
CERTIFICATIONS
UN38.3
